• The knurled solid brass lever design.
• Unique double latch mechanism: deadbolt latch paired with passage tubular latch.
• A more secure and high-precision lock body option is available.
• This zinc alloy lock plate features a neat, screw-free exterior design, offering a sleek and elegant appearance.
• Entry Sets include a complete doorknob or door lever set and a deadbolt for one door (on both sides).
• Available with 92mm and 140mm C-to-C options.

• Multi Point Lock Plate: 12"H * 2.56"W.
• Interior & Exterior Projection: 2.1".
• Hole Space: 9.76".
• Door Thick: 1-3/8" to 2".
• Deadbolt Latch: 2-3/8" or 2-3/4" adjustable.
• Passage Tubular Latch: 2-3/8" or 2-3/4" adjustable.
• Machine Screw: 1.73".
• Center-to-Center： 3.62".

This is the basic size. If you need other sizes, please contact us.

Adjustable Latch for Deadbolt:

• Most models are equipped with a latch that can be adjusted between either 2-3/8" or 2-3/4" backset.
• To adjust from 2-3/8” to 2-3/4“ backset, hold the latch faceplate still and simply rotate the latch body 180 degrees counter clockwise until it stops.
• To adjust from 2-3/8" to 2-3/4" rotate latch body 180 degrees clockwise until it stops.

Adjustable Latch for Handleset:

• Slide up S1 button and hold it.
• Push down 2-3/8" above button to slide to 2-3/4" until it stops.
• Do one more slide to the 2-3/8" until it stops.

Standard designs feature two lock latches, with optional integrated multi-point lock bodies available in various sizes. Contact us for details.

Each lock package includes an installation manual. The installation of multi-point locks is similar to that of standard door handles, and you may refer to our ‘How to Install a Door Handle’ guide. If you need further assistance, feel free to contact us.
