Quadrato Multipoint Lock with Round Knob in Matte Black

$144.00
$211.00 $144.00
Sale Sold out
Shipping calculated at checkout.

Quadrato Multipoint Lock with Round Knob in Matte Black

A 305 * 65mm multipoint lock with circular knob handles on both sides, a matte black electroplating layer all over the body, a single lock core outer door lock, a square protruding knob inside, and a simple external screw hidden structure, Whether for new construction or renovation projects, it provides a stylish and tasteful choice.

Product Features
  • The smooth solid brass knob design.
  • Unique double latch mechanism: deadbolt latch paired with passage tubular latch.
  • A more secure and high-precision lock body option is available.
  • This zinc alloy lock plate features a neat, screw-free exterior design, offering a sleek and elegant appearance.
  • Entry Sets include a complete doorknob or door lever set and a deadbolt for one door (on both sides).
  • Available with 92mm and 140mm C-to-C options.
Specifications
  • Multi Point Lock Plate: 12"H * 2.56"W.
  • Interior & Exterior Projection: 2.1".
  • Hole Space: 9.76".
  • Door Thick: 1-3/8" to 2".
  • Deadbolt Latch: 2-3/8" or 2-3/4" adjustable.
  • Passage Tubular Latch: 2-3/8" or 2-3/4" adjustable.
  • Machine Screw: 1.73".
  • Center-to-Center： 3.62".

This is the basic size. If you need other sizes, please contact us.

Function

Adjustable Latch for Deadbolt:

  • Most models are equipped with a latch that can be adjusted between either 2-3/8" or 2-3/4" backset.
  • To adjust from 2-3/8” to 2-3/4“ backset, hold the latch faceplate still and simply rotate the latch body 180 degrees counter clockwise until it stops.
  • To adjust from 2-3/8" to 2-3/4" rotate latch body 180 degrees clockwise until it stops.

Adjustable Latch for Handleset:

  • Slide up S1 button and hold it.
  • Push down 2-3/8" above button to slide to 2-3/4" until it stops.
  • Do one more slide to the 2-3/8" until it stops.

Standard designs feature two lock latches, with optional integrated multi-point lock bodies available in various sizes. Contact us for details.

Installation

Each lock package includes an installation manual. The installation of multi-point locks is similar to that of standard door handles, and you may refer to our ‘How to Install a Door Handle’ guide. If you need further assistance, feel free to contact us.
